Custom PCB Fabrication Flex Board With Durable And Aesthetic
Surfaces
Premium PCB Fabrication Delivering Exceptional Quality And
Flexibility
Printed Circuit Board Fabrication Description:
Welcome to our premium Printed Circuit Board Fabrication services.
We are committed to delivering robust and highly adaptable PCBs
using an extensive range of reinforcement materials, including PI,
FR4, and steel sheets.
Our capability to manage extensive projects is reflected in our
impressive size capacity of up to 500MM*1000MM. We employ a diverse
range of insulation materials, such as FR4 board, copper substrate,
and PET, ensuring superior electrical performance and reliable heat
resistance.
Precision is central to our services, demonstrated in our strict
control over line width and spacing, as well as a comprehensive
assortment of solder mask options. We offer both mechanical and
laser drilling for precise and clean cuts, along with a variety of
surface treatments for added durability and aesthetic appeal.
Our services extend to special processes such as thick copper
plates and high-frequency plates, with flexible molding methods,
including V-cut, CNC, and laser. Trust our PCB Fabrication services
for exceptional quality, flexibility, and precision, designed to
meet the unique needs of your complex projects.
Printed Circuit Board Fabrication Parameters:
Name | Printed Circuit Board Fabrication | Reinforcement type | PI, FR4, steel sheet, 3M glue, the electromagnetic shielding film |
Insulation | FR4 board, aluminum substrate, copper substrate, a ceramic
substrate, PI (polycumimine), PET (poly) | Maximum size | 50OMM*1000MM |
Copper foil material | Glue-free calendered copper, rubber-rolled copper, glue-based
electrolytic copper | Outer line width/line spacing | 0.065MM( 3MIL) |
number | 1-12 floors | Inner line width/line spacing | 0.065MM(3MIL) |
The finished board is thick | 0.07MM AND ABOVE (TOLERANCE +5%) | Minimum solder mask width | 0.10MM |
The inner layer is thick copper | 18-7OUM (1 ounce copper = 35UM) | Minimum mask bridge width | 0.05MM |
The outer layer is thick copper | 20-14OUM (1 plate copper = 35UM) | Minimum solder mask | 0.45MM |
Solder mask | Red oil, green oil, butter, blue oil, white oil, black oil, matte
black oil, yellow film covered white film, black film | Minimum aperture | MECHANICAL DRILLING 0.2MM, LASER DRILLING 0,1MM |
word | Red, green, yellow, blue, white, black silver | Impedance Tolerance | 10% of soil |
Surface treatment | Anti-oxidation (OSP), tin spraying, gold immersion, gold plating,
silver plating nickel plating, gold plating finger, carbon oil | Form tolerances | +0.05MM(LASER+0.005MM) |
Special processes | Thick copper plate, impedance plate, high-frequency plate,
half-hole plate, orifice plate, hollow plate, single-layer copper
foil, cross-sided gold finger plate, soft and hard combination | Molding method | V-cut, CNC, die punching, laser |
Printed Circuit Board Fabrication Factory Introduction:
Tongzhan Industrial Ltd. was established in 2011 in Shenzhen,
Guangdong Province. Tongzhan Industrial Ltd. is committed to
becoming a leading one-stop EMS supplier company, providing
customers with high-quality PCB series products. Tongzhan mainly
focuses on high-speed turnkey PCB layout design and PCB assembly
services, including PCB design, manufacturing, component
procurement, PCBA design and board making, supply chain services,
functional testing, conformal paint, complete assembly, etc. Our
corporate culture is to serve customers, customers always come
first. Customer-oriented, diligent and innovative, honest, happy,
transparent, customer-centric, professional, efficient, and
win-win. Our employees are passionate. Passion for Science. Passion
for technology.
