Printed Circuit Board Design Multilayer Plate Immersion Gold + OSP
Printed Circuit Board Design Description:
The PCB assembly we produce includes rapid turn prototype PCB
assembly, SMT/SMD assembly, through-hole assembly, hybrid
technology (SMT/through-hole), turnkey assembly, consignment
assembly, etc. They are widely used in industrial control, medical
care, automotive electronics, communications, and the Internet.
SMT, post welding, assembly to testing one-stop service supports
flexible supply.
Printed Circuit Board Design Parameters:
| Item | Technical Parameter |
| Layer | 2-64 |
| Thickness | 0.5-17.5mm |
| Copper Thickness | 0.3-12 oz |
| Min Mechanical Hole | 0.1mm |
| Min Laser Hole | 0.075mm |
| HDI | 1+n+1,2+n+2,3+n+3 |
| Max Aspect Ratio | 20:01 |
| Max Board Size | 650mm*1130mm |
| Min Width/Space | 2.4/2.4mil |
| Min Outline Tolerance | ±0.1mm |
| Impedance Tolerance | ±5% |
| Min PP Thickness | 0.06mm |
| Bow &Twist | ≤0.5% |
| Materials | FR4,High-Tg FR4,Rogers, Nelco,RCC,PTFE, M4, M6,TU862,TU872 |
| Surface Finished | HASL, HASL Pb Free Immersion Gold/Tin/Silver Osp, Immersion
Gold+OSP |
| Special Capability | Gold Finger Plating, Peelable, Carbon ink |
FAQ:
Q: What are the benefits of choosing us?
1. We focus on your needs
The growing needs of our customers drive our continued growth. The
growth management of our PCB layout, fabrication, assembly and
materials is driven by continued pressure to reduce time to market
and keep pace with emerging technologies. Co-exhibition
capabilities allow our clients to focus on their core competencies
such as R&D and sales and marketing.
2. You will benefit from our experience
Most of the staff at the same exhibition have more than 4 years of
experience in PCB design, manufacturing, assembly and parts
procurement. We handle over 2,000 cases each year.
Q. How is the delivery?
Usually, our delivery time is about four weeks, but it depends on
the actual situation when we receive your order.
If your order is urgent, please contact us directly, and we will
prioritize and do our best to give you a satisfactory delivery
time.
Printed Circuit Board Design Introduction:
The creator of PCB is the Austrian Paul Eisler, who first used
printed circuit boards in radios in 1936. In 1943, Americans mostly
used this technology in military radios, and in 1948, the United
States officially recognized this invention for commercial use.
Printed circuit boards have only been widely used since the
mid-1950s. Printed circuit boards are found in almost every
electronic device. If there are electronic parts in a device, they
are all mounted on PCBs of various sizes. The main function of the
PCB is to make various electronic components form the connection of
the predetermined circuit, which plays the role of relay
transmission. It is the key electronic interconnection of
electronic products and is known as the "mother of electronic
products".
